Max. text face width
80 mm (3.15 inch)
Max. Text face height
20 mm (0.79 inch) in roll mode
Smallest cable outer diameter
ø 2 mm (0.08 inch)
Biggest cable outer diameter
ø 16 mm
Measurements thermal foil
83 mm x 300 m
Receptor foil size (cover foil)
100 mm x 150 m / 100 mm x 100 m
Foil consumption
5 mm up to 30 mm (0.12 up to 1.18 inch)
Colors available
Marking possibilities
Text field
Variable text fields
Variable data base
Numbers
Consecutive numbering
Logos
Pictures
Date field
Barcode
etc.
Text gadget
External keyboard
PC
Connection,
RS-232 interface
Parallel interface
USB interface
Ethernet 10/100
Thermal printer
COMPA 106/12, 300dpi
Measurements
Length: 85 cm
Width: 52 cm
Height: 48 cm / 75 cm open
Weight: 43 kg
Connection
Power:
240 VAC – 50Hz – 425 VA max.115 VAC – 60Hz – 425 VA max.
(see rating plate)
Air:
0,7 MPa
